A4 Copy Paper Jumbo Roll Cutting and Packing Machine

Full automatic a4 copy paper cutting and packing machine from jumbo roll to a4 paper sheet reams.including cutting function and packaging unit.

PRODUCT DETAILS

A4 Copy Paper Jumbo Roll Cutting and Packing Machine

a4 paper making machine

a4 paper cutting and packing machine

a4 paper manufacturing machine

a4 paper cutting machine

printer machine a4 paper

second hand a4 paper making machine price

a4 paper machinery

a4 cutting paper machine

a4 manual paper cutting machine

paper machine a4

a4 paper counting machine

paper cutting machine a4


PRODUCT DETAILS


A4 COPY PAPER JUMBO ROLL CUTTING AND PACKING MACHINE


1.MACHINE DETAILS

A4 Copy Paper Jumbo Roll Cutting and Packing Machine

Speed: 3 ream/min.

Labor:2 workers at least.

Total Power:about 14kw.

Workshop size:200 square meters at least.

Transporting detail:one 40ft container


a4 paper cutting packing machine




2.CHARACTERISTICS OF A4 PAPER CUTTING PACKING MACHINE

(1) Cutting style: fix well the lower cutter and cut actively by upper cutter

(2) Cutter holder: adopts casting heavy style structure

(3) Slip bearing(2unit)

(4) Fount (2 unit)

(5) Lubricating oil can be recycled using

(6) Both upper and lower cutters adopts bar style imported balance silicic steel cutter

(7) Cutting blade (Spec.Thickness×width×Length:15×80×1150mm)

(8) Cutter position can be adjutable by hand

(9) Active transmission style: main motor transmission equipped with derailleur enable centrifugal wheel joined with connecting pole to run cutter reciprocating

(10) Main motor: by transducer speed adjusting (1unit)

(11) Transducer: (Germany Rexroth))1.5kw(1unit)

(12) Transmission: adopts gear wheel and chain wheel together structure

(13) Centrifugal wheel(2unit)

(14) Connecting pole (2unit)

(15) Slitting way: Bottom blade initiative, drive upper balde to slit.

(16) Adopts round cutters

(17) Upper cutter shaft adopts steel shaft ( 1 unit φ45 x 1500mm)

(18) Upper round cutters is made form shanghai Shenlong group (φ45 x 14.2x105mm)

(19) Bottom cutter shaft adopts steel shaft (spe. 1 unit φ55 x 1500mm)

(20) Bottom round cutter adopts shanghai shenlong cutter (φ55 x 14.2 x 80mm)

(21)  Slitting precision : ±0.2mm


3.MACHINE PICTURES


\
