60MM ID TWO-HEAD PAPER CORE MAKING MACHINE-YIDAFA MACHINERY
It is mainly used in the production of various small inner diameter paper tubes.
Inner diameter:15~60mm。
The thickness of tube wall:1~5mm.
Paper Layers:2~7 layer.
Main power:7.4kw.
60MM ID TWO-HEAD PAPER CORE MAKING MACHINE-YIDAFA MACHINERY
Machine Detail
paper layer
2-7layers
inner diameter
15-77（mm）
thickness
1-5（mm）
speed
0-45（m/min）
Fixed length mode
light control
Winding head
Two head
Cutting method
Circular knife CNC automatic
Gluing method
Double-sided glue
way to control
Frequency
Input voltage
220V,60HZ(customized by buyer)
Number of operators
1-3
total weight
1900kg
Main engine power
2*3.7kw
PLC controller
Special products
HMI
Special products
Frequency converter
ENERGY
Electrical components
Omron/Chint
Signal element
Omron/Pefun
Button/emergency stop
Siemens
Pneumatic Components
Airtac/Tianao
Host size：
4300*1500mm*1800mm
Area size：
11000mm*5000mm
Upper paper shelf
Right-angle belt hoisting
Glue frame
Automatic gluing
Bottom paper break
Automatic alarm
Bottom surface paper
stainless steel pot device
Paper guide wheel
stainless steel pipe
Host table
Stainless steel plate
Mandrel
1
Tube belt
1 pieces
Unloading rack
Stainless steel automatic
application tools
1 set
Usage:It is mainly used in the production of various small inner diameter paper tubes or cores.such as spinning tube,cloth tube,plastic film tube,toilet paper tube,agricultural film tube and leather tube.
Overview:
The cutting table is equipped with servo synchronous round knife cutting,so that the paper tube tap is uniform and the cutting end face is smooth;
the mold is screw tight,easy to replace.
Small model,small footprint,energy saving and high efficiency,fast production speed.
