1.5 reams per minute,3 reams per minute,6 reams per minute.
Copy paper roll to sheet a4 paper cutting and packaging machine full automatic.
YDF Low Price 1100mm A4 Paper Cutting and Packaging Machine
YIDAFA Low Price 1100mm A4 Paper Cutting and Packaging Machine.Widely used in writing printing paper manufacturing plant.Copy paper roll to sheet a4 paper cutting and packaging machine full automatic.This machine could cut a3,a4,a5 size paper sheet from copy paper rolls.It could pack it automatically.Different model ,different price.YIDAFA a4 paper machine could make a4 size paper sheet very fast.A4 Copy Paper Manufacturers Machine
This machine is mainly used for vertical and transverse cutting and automatically putting in order of roll paper,such as a4 copy paper, paper-plastic composite, double gummed paper etc.Slitting is controlled by servo motor ,with advantages of mechanical stability, high precision, less waste, saving labor, It’s an ideal product in paper making and packing industry.
A4 paper packaging machine is designed by ourselves on basis of producing cellophane overwrapping machine for few years’ experience, which working principle is driven by a series of mechanical structure and connecting pneumatic device, which can finish instantaneously multi-actions such as automatic feeding paper, falling paper, rectifying a deviation, cutting paper，,gluing and wrapping and so on during the process of package.
This machine integrated optics, mechanics, electricity, pneumatics and instrumentation . Also reasonable structure, advanced technique, easy operation，which is suitable for the package of global general official A4 format anti-static duplicating paper, instead of hand packing so as to reduce the working intensity and then improve the working effectiveness.
A4 Copy Paper Manufacturers Machine
Performance and structure features:
Main structure is driven by a series of cams and connecting rods and working accessories to finish the packaging. High stability, low noise.
Applying frequency conversion with multi-function digital non-ploy speed, adopting siemens PLC program controlled.
Touch screen realizing human-machine interface.
for single paper package, adopting feeding device system so as to input paper accurately.
And machine is connecting gluer and the spray adjustable.
Model 1100 A4 paper cutting and packaging machine |
Max unwinding diameter :φ1100mm Reference weight of cutting paper:40~500g Max cut width: 1100 mm Cutting length :100-500mm Cutting speed:3 reams/min. Cutting precision:±0.2mm Voltage: AC380V/220V x 50HZ Total power :20 KW |
Production capacity: | 15(packs/min) |
A4 copy paper size(standard): | 297x210mm |
Quantity of A4 paper | 500 pcs |
Voltage: | 380v 50~60hz，three phases |
Power: | 5kw |
Compressed air: | 0.6~0.7Mpa |
Overall dimensions: | 4600x1300x1680mm with safety cover |
Weight: | 1500kg |
Package material | Printed sheet paper |
A4 Copy Paper Manufacturers Machine
\
A4 Copy Paper Manufacturers Machine
A4 Copy Paper Manufacturers Machine
